Power Press |
|
Our engagement into making of calender machines have expertized us in designing Power Press. Made up of top quality products, these machines are designed to give perfection. Our experts are totally dedicated in all the stages of manufacturing of power press. These equipments can be availed as per desired specifications. |
| Product Range |
| A glimpse of some of the popular machines manufactured and exported by us: |
|
|
|
|
| SPECIFICATIONS |
5 Tons |
10 Tons |
15 Tons |
30 Tons |
50 Tons |
75 Tons |
lOO Tons |
| Bed to Ram Bottom mm |
216 |
243 |
276 |
330 |
358 |
373 |
535 |
| Bed Size mm |
260x465 |
318x482 |
360x542 |
413x644 |
555x760 |
855x592 |
967x623 |
| Bed Plate Thickness mm |
64 |
67 |
67 |
72 |
85 |
85 |
85 |
| Stroke mm |
38 |
51 |
63 |
76 |
90 |
102 |
114 |
| Crank Shaft Dia mm |
76 |
89 |
102 |
102 |
117 |
135 |
152 |
| Gear Dia mm |
457 |
533 |
610 |
678 |
796 |
873 |
1041 |
| Fly Wheel Dia mm |
406 |
457 |
660 |
600 |
686 |
762 |
864 |
| Hole in Ram for Die Clamping |
28 |
32 |
40 |
40 |
46 |
50 |
53 |
| Floor to Top of Bed mm |
762 |
735 |
726 |
773 |
826 |
820 |
850 |
| Over All Height without Motor |
1612 |
1680 |
1825 |
2010 |
2200 |
2350 |
2615 |
| Floor Area Required |
668x 765 |
620x850 |
727x850 |
715x 1013 |
885x1700 |
1000x1265 |
1145x1345 |
| No. of Strokes per Minute |
60 |
55 |
50 |
45 |
40 |
40 |
40 |
| Motor Required in H.P |
1 |
2 |
2 |
3 |
5 |
7.5 |
10 |
| R.PM.Required |
1440 |
1440 |
1440 |
1440 |
1440 |
1440 |
1440 |
| App. Wt. in Kilograms |
750 |
950 |
1150 |
2300 |
3500 |
5000 |
7000 |
|
|
Rubber Bale Cutters |
|
Offers hydraulically operated Rubber Bale Cutter to cut natural or synthetic rubber bales in pieces for further processing in Mixing Mill, Kneader and Banbury.
|
|
|
| Technical Specification |
| Total Covering Area |
: |
38" L x 32" W x 84" H |
| Ram Stroke |
: |
22" |
| Working Pressure |
: |
0.80 Tons/in² |
| Cutter Force |
: |
20 Tons |
| Cutter Length |
: |
28" |
| Cutter Width |
: |
5" |
| Motor |
: |
3 H.P. |
| Tank |
: |
65 Liters |
| To Slide Rubber |
: |
6 Rollers Fitted |
| Ram |
: |
Hard Chromed |
| Cylinder |
: |
Honed, Pipe |
| Blade |
: |
Hardened Tempered H.C.S. |
| Hydraulic Power Pack |
: |
Gear & Plunger Type, Breather Filter, Oil Filter |
| D.C. valve |
: |
Directional Control Valve & Release Valve |
|
|
| Offers Pillar Type Cross Cut Rubber Bale Cutter with Cross Blade to cut natural or synthetic rubber bales in pieces for further processing in Kneader/ Internal Mixer. |
|
|
|
| Technical Specification |
| Total Covering Area |
: |
40" L x 35" W x 85" H |
| Ram Stroke |
: |
23" |
| Working Pressure |
: |
0.80 Tons/in² |
| Cutter Force |
: |
20 Tons |
| Cutter Length |
: |
28" |
| Cutter Width |
: |
5" |
| Motor |
: |
5 H.P. |
| Tank |
: |
65 Liters |
| Ram |
: |
Hard Chromed |
| Cylinder |
: |
Honed, Pipe |
| Blade |
: |
Hardened Tempered H.C.S. |
| Hydraulic Power Pack |
: |
Gear & Plunger Type, Breather Filter, Oil Filter |
| D.C. valve |
: |
Directional Control Valve & Release Valve |
|
|
Hydraulic Cylinders & Pneumatic Cylinders |
|
|
|
|
Major Construction Details :
Quality - Hydraulic cylinders and Pneumatic cylinders are manufactured as per international Quality standards under strict supervision by our quality assurance departments.
Tube - Seamless honed barrels (Steel/Brass/Aluminum) to a micro-finish provide long piston life and prevent failure of the cylinder. The barrel material is selected on the basis of application & working pressure.
Piston Rod - High strength steel piston rod of EN - 9 material is precision ground and hard chrome plated and regrinded to ensure anti-corrosion and maximum life.
Piston - Cast Iron.
Cylinder Base - Special cylinders using one piece Barrel are also produced on request. One end of the cylinder is precision bolted incase of low pressure cylinders, but in case of high pressure cylinders the Base is threaded & then welding with utmost accuracy & precision.
Seals - International quality Seals that are self-adjusting for long trouble free life.
Mounting - All mounts are of steel. |
|
Range of Hydraulic Cylinders :
» Type: - Double / Single Acting
» Bore Size: - 25mm upto 1100 mm
» Stroke: - As per customer requirement
» Max. Pressure: - 10 upto 700 Bar |
|
|
Range of Pneumatic Cylinders :
» Working Pressure:-150 P.S.I.
» Stroke:- As per customer requirement
» Cushioning is also provided on request |
|
|
Non- IBR Boilers |
|
|
|
|
|
| It is unique with versatile and easy-to-operate features with fireboxes suitably located. It incorporates up to 4 stages, with separate steam and hot water tanks to accomplish the job safely and efficiently. It is capable of developing capacity of 100 to 600 ibs/hr. It finds easy and ready application in various industries like textile, chemical, rubber, food, pharmaceutical, hotel foam, rubber etc. |
|
